• 大扭矩伺服电驱技术
  • High torque servo electric drive technology
  • 液压胀紧系统解决错口问题
  • Hydraulic expansion and tightening system solves the problem of misalignment
  • 快速响应电磁刹车系统
  • Quick response electromagnetic brake system
  • 机体尺寸大幅缩减提升过弯性能
  • Significantly reduced body size enhances cornering performance
  • 无线遥控控制
  • Wireless remote control
  • 快速对口及焊接
    Fast climping pipe and finish root welding.(Clamping pipe and doing root welding just need about 5 mins)




山地柔性内焊机 | 管道内环缝自动焊机

Mountain Flexible Internal Automatic welding machine

技术规格
规格型号

Model number

DW48/56-8H-D
电池容量

Battery Capacity

230AH×3组
适用管径

Application

Φ1219mm-Φ1422mm
焊接单元数量

Welding units quantity

8个
行走速度

Moving speed

0-60m/min
爬坡能力

Climbing capability

≤30°
通过弯管曲率

Passing bend rate

5/6倍D
焊接时间

Welding time

≤120S
焊丝直径

Welding rod diameter

Φ0.9-Φ1.2mm
额定工作压力

Rated working pressure

5-7Mpa
额定工作电压

Rated working voltage

DC24V
适应海拔高度

Adapting altitude

0-3500m
工作环境温度

Working temperature

-50℃-65℃
规格尺寸

Dimension

4600×1250×1200mm(长宽高)
整机重量

Weight

2400Kg
